MYNX CONTROL Vascular Closure Device

Name: Cordis
Price range: $

The innovative design and predictable deployment of MYNX CONTROL^® Vascular Closure Device (VCD) delivers outstanding performance and control for consistently secure arterial closures.

Close with confidence. Leave nothing behind.

MYNX CONTROL VCD integrates dual-mode active sealing and reabsorbability with a next-generation delivery system to maximize predictability, safety, and ease of use in 5F, 6F, and 7F sizes.

Secure extravascular closure in a wide range of clinical scenarios.

With exceptional versatility, MYNX CONTROL VCD offers dependable closure with nothing left behind*—even in cases where using a different vascular closure device might be unsuitable.

Safe for bifurcations^2†

Useful on antegrade punctures³

No footplates, sutures, or metal implants to impede reaccess

Balloon visualization verifies position

_{† Confirm vessel size is ≥ 5 mm}

Product Highlights

Sheath Catch

Compatible with procedural sheath limited the need for sheath exchanges.

Button #1

Deploys and compresses the sealant.

Tension Indicator

Provides visual confirmation of device position for proper sealant deployment.

Button #2

One-step balloon withdrawal.

Ergonomic Handle

Facilitates ease of use for predictable deployment.

The Science of Active Extravascular Sealing

MYNX CONTROL VCD consists of two configurations of polyethylene glycol (PEG), for durable hemostasis.

SAFE
No foreign-body reaction or scar tissue formation¹
SYNTHETIC
Non-thrombogenic¹
HYDROLYTIC DEGRADATION
Fully resorbs through hydrolysis—no enzymatic breakdown¹
MYNX GRIP TIP
Activated by body temperature and pH Interlocks with contours of the vessel by actively attaching to the artery, for secure mechanical closure
MYNX^® SEALANT COLUMN
Expands to 3-4 times its original size on contact with blood and subcutaneous fluids, creating a matrix structure for clot formation

Request Additional Information

Safety by the Numbers.

MYNX CONTROL VCD has been clinically proven to reduce surgical complications, expedite recovery, shorten hospital stays, and increase patient comfort.^2-7‡

Increased Patient Comfort

In a blinded, randomized clinical study, pain at closure and pain increase from baseline to close were significantly lower for MYNX CONTROL VCD than Angio-Seal^™ vascular closure device.⁷

Access-site bleeding and vascular injury

Reduced incident rate In a blinded, randomized clinical study, there was a significantly reduced incident rate for MYNX Portfolio of products than Angio-Seal VCD.

Resources

MYNX CONTROL VCD Step-by-Step Guide Brochure

MYNX CONTROL VCD Step-by-Step Procedural Poster

Cordis Cardiovascular Catalog

Ordering Information

Vascular Closure Devices

Product	Size	Order No.	Quantity	Components
MYNX CONTROL^® Vascular Closure Device	5F	MX5060	10 ea/box	1x MYNX CONTROL^® VCD including balloon catheter and integrated polyethylene glycol extravascular sealant 1x 10 ml locking syringe
MYNX CONTROL^® Vascular Closure Device	6F / 7F	MX6760	10 ea/box	1x MYNX CONTROL^® VCD including balloon catheter and integrated polyethylene glycol extravascular sealant 1x 10 ml locking syringe

Procedural Sheaths (Recommended)

Product	Size	Order No.	Quantity	Components
AVANTI® + Sheath Introducer 11 cm	5F	402-605X	5 ea/box	1x Mid-length 11cm Cannula 1x Mini-Guidewire
AVANTI® + Sheath Introducer 11 cm	6F	402-606X	5 ea/box	1x Mid-length 11cm Cannula 1x Mini-Guidewire
AVANTI® + Sheath Introducer 11 cm	7F	402-607X	5 ea/box	1x Mid-length 11cm Cannula 1x Mini-Guidewire

References

Clinical Articles

_{The MYNXGRIP™ Vascular Closure Device Hoang Minh Thai, MD, FACC, FSCAI, and Barry S. Weinstock, MD. Endovascular Today. April 2012.}

_{Successful Reduction of Surgeries Secondary to Arterial Access Site Complications A Retrospective Review at a Single-Center with an Extravascular Closure Device. Noor S, Meyers S, Curl R. Vascular and Endovascular Surgery. May 2010;44(5):345-9.}

_{A Prospective Randomized Single-blind trial of Patient Comfort Following Vessel Closure Extravascular Synthetic Sealant Closure Provides Less Pain than a Self-tightening Suture Vascular Compression Device. Fargen KM, Hoh BL, Mocco J. J Neurointerv Surg. 2011;3(3):219-23}

_{Mynx Vascular Closure Device Early Ambulation Study Vikranth R. Gongidi, DO; Ahsan Jafir, DO; and Vijay Verma, MD, FACC, FSCAI. Endovascular Today. October 2013}

_{Occurrence of angiographic femoral artery complications after vascular closure with Mynx and AngioSeal Fargen KM, Velat GJ, Lawson MF, et al. Journal of Neurolnterventional Surgery. 2013;5(2):161-4}

_{Use of Vascular Closure Device After Access of Common Femoral Artery Through an Existing Stent George JC. Vascular Disease Management. 2012;9(5):E68-E70.}

_{Two Years of Extravascular Closure With the MYNX CONTROL™ Vascular Closure Device The Baptist Memorial Hospital experience revisited. David Wolford, MD, FACC. Endovascular Today. August 2010.}

_{Why Extravascular Closure? The Baptist Memorial Hospital Experience with the Mynx Vascular Closure Device David Wolford, MD, FACC. Endovascular Today. August 2009.}

_{The Safety and Efficacy of an Extravascular, Water-Soluble Sealant for Vascular Closure Initial Clinical Results for Mynx. D. Scheinert MD et al. Catheterization and Cardiovascular Interventions. November 2007.}

Footnotes

^{1. Scheinert D, Sievert H, Turco MA, et al. The safety and efficacy of an extravascular, water‐soluble sealant for vascular closure: Initial clinical results for Mynx. Cathet Cardiovasc Intervent. 2007 Oct;70:627-633.}

^{2 MYNX CONTROL Vascular Closure Device Instructions for Use.}

^{3 Pruski MJ Jr, Blachut AM, Konkolewska M, et al. MynxGrip for closure of antegrade puncture after peripheral interventions with same-day discharge. Vasc Endovasc Surg. 2017 Feb;51(2):67-71.}

^{4 Baker NC, Escarcega RO, Lipinski MJ, et al. Active versus passive anchoring vascular closure devices following percutaneous coronary intervention: a safety and efficacy comparative analysis. J Interv Cardiol. 2016 Feb; 29(1): 108-112.}

^{5 Hutchings D, Hayat A, Karunakaran A, Malik N. Success, safety, and efficacy of the Mynx femoral closure device in a real-world cohort: single-center experience. J Invasive Cardiol. 2016 Mar;28(3):104-108.}

^{6 Noor S, Meyers S, Curl R. Successful reduction of surgeries secondary to arterial access site complications: a retrospective review at a single center with an extravascular closure device. Vasc Endovascular Surg. 2010 Jul;44(5):345-349.}

^{7 Fargen KM, Hoh BL, Mocco J. A prospective randomized single-blind trial of patient comfort following vessel closure: extravascular synthetic sealant closure provides less pain than a self-tightening suture vascular compression device. J NeuroInterv Surg. 2011 Sep; 3(3): 219-223.}

^{† Confirm vessel size is ≥ 5 mm}

^{‡Time to discharge eligibility as compared to manual compression. MATRIX Clinical Trial (IDE# G030182)}

IFU

Please refer to the Instructions for Use for complete information, including indications, precautions, warnings, and potential adverse events.

Customer Service and Ordering Information

In the United States, email us your question or order, or call us at 800.327.7714.
